Clymer Shop Repair Manual

Clymer Yamaha V-Star 650 1998-2011 Repair Manual

Clymer repair manuals are written specifically for the do-it-yourselfer.

For routine maintenance or more extensive repairs involving engine and transmission disassembly, it has all the information you need.

Step-by-step procedures, detailed photography and extensive use of exploded views based on the complete disassembly of the machine.

Clymer shop manuals are perfect for everyone, from the first-time user to the seasoned professional.

CHAPTER ONE / GENERAL INFORMATION

CHAPTER TWO / TROUBLESHOOTING

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP

Pre-ride checks / Maintenance intervals / Tires / Battery / New battery installation / Battery electrical cable connectors / Periodic lubrication / Periodic maintenance / Tune-up

CHAPTER FOUR / ENGINE TOP END

Engine principles / Servicing engine in the frame / Cylinder head covers / Cylinder head / Rocker arms / Camshaft / Cam chain and chain guides / Valves and valve components / Cylinder block / Piston and piston rings

CHAPTER FIVE / ENGINE LOWER END

Servicing engine in the frame / Engine / Alternator cover / Stator and pickup coils / Alternator rotor and starter gears / Starter clutch / Middle driven gear assembly / Middle drive pinion gear / Primary drive gear / Oil pump / Oil strainer / Crankcase / Crankshaft / Connecting rods / Break-in

CHAPTER SIX / CLUTCH AND EXTERNAL SHIFT MECHANISM

Clutch cover / Clutch / Clutch release mechanism / Clutch cable replacement / Primary drive gear and oil pump spur gear / External shift mechanism

CHAPTER SEVEN / TRANSMISSION AND INTERNAL SHIFT MECHANISM

Transmission / Internal shift mechanism / Shift pedal/foot peg assembly

CHAPTER EIGHT / FUEL, EMISSION CONTROL AND EXHAUST SYSTEMS

Air filter housing / Surge tank assembly / Carburetor operation / Carburetor / Throttle position sensor / Carburetor heater system / Fuel cut solenoid valves/Fuel level / Throttle cable / Choke cable / Fuel tank / Fuel valve / Fuel filter / Fuel pump bracket / Air induction system / Evaporative emission control / Exhaust system

CHAPTER NINE / ELECTRICAL SYSTEM

Charging system / Stator / Voltage regulator/rectifier / Ignition system / Ignition coil / Pickup coil / Relay unit / Spark plug / Igniter unit / Starting system / Starter motor / Starting circuit cut-off relay / Starting system diode / Starter relay / Lighting system / Headlight / Meter assembly / Taillight / Signal system / Brake light / Neutral indicator light / Turn signals / Horn / Fuel pump system / Carburetor heater system throttle position sensor / Fuel cut solenoid valves/Switches / Wiring connectors / Fuses/Self-diagnostic system

CHAPTER TEN / FRONT SUSPENSION AND STEERING

Bike stand / Front wheel / Front hub / Rim and spoke service / Wheel balance / Tire changing / Handlebar / Steering head / Front fork

CHAPTER ELEVEN / REAR SUSPENSION

Rear wheel / Rear hub / Final gear case and drive shaft / Shock absorber / Swing arm

CHAPTER TWELVE / BRAKES

Disc brakes / Front brake pad replacement / Front caliper / Front master cylinder / Front brake hose replacement / Brake disc / Bleeding the system / Rear drum brake / Brake pedal/foot peg assembly / Brake rod assembly

CHAPTER THIRTEEN / FRAME

Seat / Front fender / Rear fender / Frame neck cover / Battery box cover / Right side cover / Tool box cover / Left side cover / Side stand / Foot peg / Frame

COLOR WIRING DIAGRAM

Product Note: This manual is not exclusive to the model specified in this listing and contains information on a variety of makes and models.

Specification	Details
Country of Origin	Varies (make selection above)
ISBN	Varies (make selection above)
Pages	Varies (make selection above)
Quantity	Varies (make selection above)
ISBN	9781599696195
Pages	376

Vehicle Fitment

Fitment is guaranteed or your money back plus free return shipping.
Don’t waste time installing a product that doesn't fit. We worked hard ensuring that this product is an exact fit on the vehicles listed below.

V-Star 650 Classic 1998-2010
V-Star 650 Custom 1998-2011
V-Star 650 Silverado 2003-2010
