Clymer BMW R50/5 through R100GS PD 1970-1996 Repair Manual
Clymer repair manuals are written specifically for the do-it-yourselfer.
For routine maintenance or more extensive repairs involving engine and transmission disassembly, it has all the information you need.
Step-by-step procedures, detailed photography and extensive use of exploded views based on the complete disassembly of the machine.
Clymer Manuals are perfect for everyone, from the first-time user to the seasoned professional.
CHAPTER ONE / GENERAL INFORMATION CHAPTER TWO / TROUBLESHOOTING
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Routine safety checks / Maintenance intervals schedule / Oil and filter change / Transmission oil check / Final drive oil change / Drive shaft oil change / Air filter change / Control cable lubrication / Periodic lubrication / Periodic maintenance / Camshaft chain tensioner adjustment / Cylinder head nut torque check / Adjust valve clearance / Ignition timing / Breaker point service / Compression test / Carb synchronization / Tune-up / Spark plugs / Specifications
CHAPTER FOUR / ENGINE
Removal installation / Engine front cover / Cylinder head and cover / Rocker arm / Valves and components / Cylinder / Pistons and rings / Valve lifters / Connecting rods / Oil pump / Oil pan and strainer / Oil cooler / Timing chain cover / Camshaft, timing chain, timing sprockets and chain tensioner / Crankshaft / Crankcase / Break-in / Specifications
CHAPTER FIVE / CLUTCH
Clutch and flywheel / Clutch release mechanism / Clutch cable / Specifications
CHAPTER SIX / TRANSMISSION, GEARSHIFT MECHANISM AND KICKSTARTER
Transmission housing / Gearshift mechanism / Kickstarter / Specifications
CHAPTER SEVEN / CARBURETORS, EMISSION CONTROLS AND EXHAUST SYSTEM
Carburetor operation adjustment service / Slide-type carburetor Bing and Dell' Orto / Bing constant velocity type carburetor / Air filter case / Throttle cable / Choke cable / Fuel tank / Fuel shutoff valves / Fuel filter / Crankcase breathe system / Air injection system / Evaporative emission controls system / Exhaust system / Specifications
CHAPTER EIGHT / ELECTRICAL SYSTEM
Charging system / Alternator / Voltage regulator / Diode board / Battery / Contact breaker-point ignition system / Ignition control unit / Ignition coils / Starting system / Starter / Starter relay / Lighting system / Headlight / Lights / Switches / Electrical connectors / Instrument cluster / Relays / Specifications
CHAPTER NINE / FRONT SUSPENSION AND STEERING
Wheel and hub / Handlebar / Steering head and stem / Steering head bearing race / Front fork / Front fork removal and installation / Front fork disassembly and assembly / Specifications
CHAPTER TEN / REAR SUSPENSION AND FINAL DRIVE
Wheel and hub / Shock absorber / Swing arm and drive shaft / Final drive unit / Pinion gear-to-ring gear adjustment / Taper roller bearing preload / Specifications
CHAPTER ELEVEN / BRAKES
Front rear drum brake / Front rear disc brake / Brake pad / Front rear master cylinder / Front rear caliper / Brake hose and line / Brake bleeding / brake pedal / Specifications
CHAPTER TWELVE / FRAME AND BODY
SUPPLEMENT / 1990 AND LATER SERVICE INFORMATION INDEX
WIRING DIAGRAMS
Product Note:This manual is not exclusive to the model specified in this listing and contains information on a variety of makes and models.
Specification
Details
ISBN
9780892878543
Pages
816
Vehicle Fitment
Fitment is guaranteed or your money back plus free return shipping.
Don’t waste time installing a product that doesn't fit. We worked hard ensuring that this product is an exact fit on the vehicles listed below.
BMW
R 100 1979-1984
R 100 CS 1981-1984
R 100 GS 1987-1995
R 100 GS PD 1990-1995
R 100 RS 1976-1984, 1987-1993
R 100 RT 1978-1984, 1987-1995
R 100 S 1976-1980
R 100 T 1979-1984
R 100/7 1976-1979
R 50/5 1970-1973
R 60/5 1970-1973
R 60/6 1974-1976
R 60/7 1977-1978
R 65 1978-1987
R 65 LS 1981-1985
R 75/5 1970-1973
R 75/6 1974-1976
R 75/7 1977
R 80 1977-1987
R 80 G/S 1980-1986
R 80 RT 1982-1987
R 80 ST 1983-1984
R 80/7 1977-1981
R 90 S 1974-1976
R 90/6 1974-1976
