Feuling Vented Oil Dipstick

Item Number: 393425

$279.95

Edit Vehicle

888-575-6570

Product Description

Feuling

Feuling Vented Oil Dipstick

  • Billet dipsticks vent/breathe excessive crank case pressure from the oil tank through a PVC style breather consisting of an oil separator system, perforated disc, replaceable filter element and umbrella flapper valve
  • Screws into the factory oil fill spout as a stock replacement part
  • These breathing dipsticks remove unwanted build-up of blow by pressure, all internal combustion engines have a certain amount of blow by
  • Larger cubic inch, worn and or loose ring clearance as well as engines pushed to their limits generally have increased blow by
  • Blow by is pressure that is forced past the rings and cylinders, pushed into the crankcase and then forced back into the oil tank
  • Dipsticks help remove this unwanted pressure through a (CVS) Crankcase Ventilation System
  • Feuling test results show a decrease in engine oil sump levels, more freely/smoother revving engine, increased MPG and decreased blow-by
  • Dipsticks vent/breath excessive crank case pressure from the oil tank through a breather system consisting of a oil separator system, perforated disc, replaceable filter element and umbrella flapper valve
  • Includes two venting styles options to choose from when installing the dipstick
  • Option 1: 1/8" NPT breather vent fitting with internal porous filter element (this option gives a clean look, however it can produce an oil misting/residue out of the element on engines with excessive leakdown/blow by)
  • Option 2: Quick-disconnect coupler fitting with rubber hose and filter element (this option will run any excessive oil misting/residue through the line and into the filter element, however this option does requires disconnecting the fitting in order to check the oil
  • Option 2 is Feuling's preferred option as it breathes more than Option 1
  • For Option 2, Feuling recommends routing the line up the frame rail, up under the seat/abs area then back down along the right side frame rail and the filter element can fit cleanly between the engine/trans matting area on the inside of the lower right frame rail
  • Checking oil level: There are two ways to read the oil level with this dipstick, with the bike on the jiffy stand (FHS) or the bike upright and level (FHU)
  • FHS = FULL HOT STAND: if reading the dipstick with the bike on the jiffy stand you will take your reading from the dimples labeled FHS (Full Hot Stand)
  • FHU = FULL HOT UPRIGHT: when reading the dipstick with the bike upright and level you will take the reading from the dimples labeled FHU (Full Hot Upright)
  • Available in polished or fade-resistant black
  • Made in the USA

Spec Details
Color Varies (make selection above)
Country of Origin USA
Finish Varies (make selection above)
Material Aluminum
Quantity Each

Vehicle Fitment

Fitment is guaranteed or your money back plus free return shipping. Don't waste time installing a product that doesn't fit. We worked hard ensuring that this product is an exact fit on the vehicles listed below.

Harley Davidson

  • FLDE Softail Deluxe 2018-2020
  • FLFB Softail Fat Boy 2018-2019
  • FLFBS Softail Fat Boy 114 2018-2021
  • FLHC Softail Heritage Classic 2018-2021
  • FLHCS Softail Heritage Classic 114 2018-2021
  • FLSB Softail Sport Glide 2018-2021
  • FLSL Softail Slim 2018-2021
  • FXBB Softail Street Bob 2018-2020
  • FXBR Softail Breakout 2018-2019
  • FXBRS Softail Breakout 114 2018-2020
  • FXDR Softail 114 2019-2020
  • FXFB Softail Fat Bob 2018-2019
  • FXFBS Softail Fat Bob 114 2018-2021
  • FXLR Softail Low Rider 2018-2020
